Display
|
Panel Size: Wide Screen 23.8"(60.5cm) 16:9
|
| |
Color Saturation : 72%(NTSC)
|
| |
Panel Backlight / Type : IPS
|
| |
True Resolution : 1920x1080
|
| |
Display Viewing Area(HxV) : 527.04 x 296.46 mm
|
| |
Display Surface : Non-glare
|
| |
Pixel Pitch : 0.275 mm
|
| |
Brightness(Max) : 250 cd/
|
| |
Contrast Ratio (Max) : 1000:1
|
| |
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
|
| |
Viewing Angle (CR10) : 178(H)/178(V)
|
| |
Response Time : 5ms (Gray to Gray)
|
| |
Display Colors : 16.7M
|
| |
Flicker free
|
| |
Refresh Rate(max) : 75Hz
|
|
Video Feature
|
SPLENDID Video Preset Modes : 8 Modes (sRGB Mode/Scenery Mode/Theater Mode/Standard Mode/Night View Mode/Game Mode/Reading Mode/Darkroom Mode)
|
| |
Skin-Tone Selection : 3 Modes
|
| |
Color Temperature Selection : 4 Modes
|
| |
QuickFit (modes) : Yes (Alignment Grid/Paper/Photo Modes)
|
| |
GamePlus(modes) : Yes (Crosshair/Timer/FPS Counter/Display Alignment)
|
| |
Low Blue Light : Yes
|
| |
HDCP support : Yes
|
| |
VividPixel : Yes
|
| |
EyeCheck : Yes
|
| |
FreeSync technology supported
|
| |
Adaptive-Sync supported :Yes
|
|
I/O Ports
|
Signal Input : HDMI, D-Sub
|
|
Signal Frequency
|
Analog Signal Frequency : 24 ~83 KHz (H) /48 ~75 Hz(V)
|
| |
Digital Signal Frequency : 24 ~83 KHz (H) /48 ~75 Hz(V)
|
|
Power Consumption
|
Power on (Typical) : <13W
|
| |
Power Saving Mode : <0.5W
|
| |
Power Off Mode : <0.5W
|
| |
Voltage : 100-240V, 50 / 60Hz
|
|
Mechanical Design
|
Chassis Colors : Black
|
| |
Tilt : +20~-10
|
| |
VESA Wall Mounting : 100x100mm
|
| |
Slim Design : Yes
|
| |
Frameless Design : Yes
|
|
Security
|
Kensington lock
|
|
Dimensions
|
Phys. Dimension with Stand (WxHxD) : 541.7 x 394.9 x 208.4 mm Phys. Dimension without Stand (WxHxD) : 541.7 x 322.87 x 40.5 mm
|
| |
Box Dimension (WxHxD) : 602 x 466 x 145 mm
|
|
Weight
|
Net Weight (Esti.) : 4 kg
|
| |
Net Weight without Stand (For VESA Wall Mount) (Esti.) : 3.03 kg
|
| |
Gross Weight (Esti.) : 6.8 kg
|
|
Accessories
|
VGA cable(Optional)
|
| |
Power cord
|
| |
Power adapter
|
| |
Quick start guide
|
| |
HDMI cable (Optional)
|
| |
Warranty Card
|
|
Compliance and Standards
|
Energy Star, BSMI, CB, CCC, CE, CU, ErP, FCC, KCC, PSE, RoHS, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1), MEPS, RCM, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, PC recycle, JM, CEC
|
|
Note
|
* Adaptive-Sync/FreeSync only can be activated within 48Hz ~ 75Hz via HDMI port
|
